SENNDIK SDK32-24243N Zero-Crossing Solid State Relay
Industrial-grade SSR designed for AC load control with 24VDC input and 24~280VAC output (3A rated current). Engineered for precision switching:
Core Features
?? Zero-Crossing Trigger: Eliminates inrush current (max turn-on ??10ms @50Hz)
?? Robust Protection:
??- 600Vpk transient voltage withstand
??- dv/dt rating: 100V/??s
??- 2500VAC dielectric isolation (input/output)
?? Ultra-Compact: 3g weight, ideal for high-density PCBs
?? Wide Temperature Range: Operates at -30?? to +80?? (derating above 40??)
Technical Specifications
Parameter Value
Control Voltage Range 19.2-28.8VDC
Min. Turn-on Voltage 19.2VDC
Max. Off-state Leakage 1.5mA
Turn-off Time ??10ms @50Hz
Isolation Resistance 1000M?? @500VDC
Typical Applications
? Resistive heating systems
? AC motor starters
? Lighting controls (varistor required for inductive loads)
